10-5TRP

Reduced Palm Heavy Duty Terminals - Copper Tube

Features

Application: For L.V. circuit breakers with reduced space terminal blocks for immediate and easier installation

Material: Manufactured from seamless copper tube to BS EN 12449:1999

Finish: Electro Tin plated to BS 1872:1974

  • All terminals are manufactured from 99 .5% copper and fully annealed to ensure optimum ductility to avoid severe deformation such as cracking and splitting when crimped
  • Terminals are supplied with an inspection window which enables the user to ensure full and correct insertion of the conductor and a flared entry ensures a smooth transition from terminal to conductor
  • Internal barrel diameters suit standard cables as defined in BS 6360
  • All SWA terminals are identified on the palm with cable size (and stud hole size) to ensure correct selection of the appropriate tool and dies

Approved to: BS EN 61238-1:2003 Grade A

Certified by: Dekra International

All SWA Copper Tube Terminals are despatched in sealed SWA branded bags to ensure quality & traceability for our customers

Product CodeDescriptionPack QtyEANTSI Code
10-5TRPReduced Palm Copper Tube Terminal 10mm²5050291068819397609884
16-5TRPReduced Palm Copper Tube Terminal 16mm²5050291068826397609907
25-5TRPReduced Palm Copper Tube Terminal 25mm²5050291068833397609910
35-6TRPReduced Palm Copper Tube Terminal 35mm²5050291068840397609936
50-6TRPReduced Palm Copper Tube Terminal 50mm²5050291062718397609965
70-6TRPReduced Palm Copper Tube Terminal 70mm²5050291068871397609981
70-8TRPReduced Palm Copper Tube Terminal 70mm²15050291062725N/A
95-8TRPReduced Palm Copper Tube Terminal 95mm²5050291062732397610006
120-8TRPReduced Palm Copper Tube Terminal 120mm²5050291062749397610080
120-10TRPReduced Palm Copper Tube Terminal 120mm² 5050291062756397610132
150-8TRPReduced Palm Copper Tube Terminal 150mm² 5050291062763397610145
150-10TRPReduced Palm Copper Tube Terminal 150mm² 105050291062770397610174
185-10TRPReduced Palm Copper Tube Terminal 185mm² 5050291062787397610187
240-10TRPReduced Palm Copper Tube Terminal 240mm² 5050291062800397610226
240-12TRPReduced Palm Copper Tube Terminal 240mm²5050291062817397610242
240-16TRPReduced Palm Copper Tube Terminal 240mm² 5050291068857397610268
300-10TRPReduced Palm Copper Tube Terminal 300mm²15050291061926406643472
300-12TRPReduced Palm Copper Tube Terminal 300mm²5050291068864397610417
